SDRlab 122-16 External Clock Standard Kit
CAUTION: This board needs an external clock signal 122.88MHz in order to boot and function!
SDRlab 122-16 External Clock is based on the SDRlab 122-16 digitizer model that is modified to be used with an external clock oscillator, which is important, especially for RF applications that operate at other frequencies and may require higher accuracy clock or synchronization.
With this modification, users can provide their own clock for the Red Pitaya device through the E2 extension connector.
External clock modification advantages:
– Tailored for SDR & other RF applications, HF and 50MHz bands
– No DC coupling! minimum RF Input frequency (-3dB): 300kHz
– Comes with two 16-bit ADC 50 ohm inputs; 14-bit DACs 50 Ohm outputs
– Three times bigger dual-core ARM Cortex A9 + Xilinx Zynq 7020 FPGA
– Bigger FPGA provides more real-time processing capabilities
– Hardware compatible with HPSDR
– Improved distortions, dynamic range, sensitivity, noise & crosstalk
SDRLAB 122-16 External clock is based on the SDRlab 122-16 model that is modified to be used with an external clock oscillator, which is important specifically for RF application that operate at other frequencies, require better clock or clock synchronization.
With this modification, users can provide their own clock for the Red Pitaya device through the E2 extension connector.
CAUTION: This board needs an external clock signal 122.88MHz in order to function !
Key features:
– Credit-card-sized RF signal acquisition and generation platform
– Dual-Core ARM Cortex-A9 MPCore AMD Xilinx ZYNQ 7020 SoC (CPU & FPGA)
– FPGA and CPU integration for enhanced performance
– Open-source design for customization and flexibility
– Ethernet connectivity
– Configurable units of measurement for seamless integration
– Ideal for creating SDR transceivers
– Innovative lab tool for various applications
– Two simultaneous fast analog inputs and two outputs
– Possibility of integration into own system/product
– Open-source software code
– Works with Linux, Windows PC, Android, IOS, basically anything with a web browser
– Free web apps (oscilloscope & signal generator, spectrum, logic analyzer, SDR, VNA)
– Can be controlled remotely using C, LabVIEW, MATLAB, Python, or Scilab
– Can be programmed to meet custom needs
Applications:
– Software-defined radio
– Reverse beacon network (RBN)
– Skimmer server
– Communications
– Diversity radio systems
– RF HF applications
– Space and military RF applications
– FFT analysis and signal measurement
– Environmental electromagnetic measurements
– Universal test platform for RF prototyping
What is in the box
– Red Pitaya SDRlab 122-16 digitizer board
– SD card (16GB, class 10)
– Ethernet cable (1m)
– Power supply (5V, 2A)
